joey_martin

Do yourself a favor and use keynotes rather than fills...

As a designer that is in the field weekly visiting our job sites, I can tell you 100% that the trim carpenters will be telling stories about the jerk designer that thought it was cool putting crown molding on a vaulted ceiling. I am one of those designers....sadly....I don't do that any longer.

Nail a cleat up and fasten to the cleat.

2 different plan views.

Use a layer set and the plot view camera.

Your stem wall needs to be a pony wall. no need for a workaround or pulling the brick down, just create that stem wall and use it for your foundation.

You have a ton of cleanup to do on the walls, but if you look at the WIC in the bottom right of your plan I fixed that wall and rebuilt the foundation, which you didn't have built.

2000SF Lily Plan.zip

Are you sure you want the brick extended OVER the slab, or setting on brick ledge that is part of the slab?

That setting is in in the wall definition.

Just sent a ticket in.

Same....

Change the 2D symbols to whatever you want them to be.

Short answer. No.

Long(ish) answer. Maybe. There may be a way to export the Chief model as a 3D .dxf or .dwg and then import and maybe....(?)

Honestly, I would simply draw those as a CAD box and when I had the shape right I would make a solid and give it the depth/width it needs. These are not typical stairs, so just like in the field where they won't likely be built with regular stringers, you will need to use all the tools and think it over a bit.

I don't think it will build automatically, but using the blocking(roof) tool you can draw the line of blocking in there and edit the entire line of blocking at once.

10 hours ago, Japyhala0 said:

I have Had the same problem with stud spacing. Has anyone come up with a solution?

The solution is to properly specify the framing. In my 20+ years of using Chief I have never encountered this problem.

Are adding text OVER the dim line or using the text options within the dimension dialog box?

https://www.chiefarchitect.com/products/3d-viewer/

What are your framing preferences set up as? Looks to me like your rafter framing as specified is larger then your fascia and sub-fascia specification. You need to set those ahead of time to get the right results the first time.

You must have deleted the "Attic Walls" which is the best way to do those. I have an attic wall created that is 1.5" thick with no material and framing unchecked so that the sheathing, housewrap, and siding are all there, but the truss fits in and replaced the "wall framing".

Add that "attic wall" back in and all the other factors you mentioned take care of themselves.

PM me the details and I will have a look.

11 hours ago, para-CAD said:

I hope that’s going to be metal or some kind of synthetic. When I see the word “framing” I default assume wood

The general framing tool allows for making those members metal. Either "C" channels or steel boxes just like what is shown in the OP pic.
