Good morning, everyone. I was wondering about the default layers assigned to library objects. Is there a reason bathroom and plumbing fixtures are placed on “Fixtures, Interior” instead of a dedicated “Fixtures, Plumbing” layer? Cabinets have their own layers, and electrical fixtures come in under “Electrical,” so having a separate default layer for plumbing fixtures seems like a logical way to organize them. I’m currently making these changes in my own template, but I’m curious whether there’s a practical reason for the existing setup. Would anyone else find it helpful if the default layers were organized more clearly by category from the beginning?

I just dont on here to look for the same answer.... Sigh....

Thank you for your help. You are correct, it was the old catalog.

I have had this problem scence I installed X17. I called support and they were not much help. Has anyone else had this problem?

I think that is what happened. But I didn't know what to unclick LOL

Thank you, Sir! I knew it was something simple. I could not figure out how to get "Help" to help me find it.

I have somehow enabled the center markers to be displayed. Can someone tell me how to disable them?

Does anyone have a file for a large griddle? I need it for a project. I can not find one anywhere.

I noticed that after putting that up there. I am not sure why it did that. I will put up a better plan today.

I have zipped and attached one of the files I am talking about. Test - PDS - Residential Template.zip

For the life of me I can not figure out why these walls stopped connecting after I made this new template. I am sure its something easy. Any help would be appreciated.

This is basically what I do now. I guess I will just stick with it.

I am starting to remember why I never did set this up. There is no way to make the font smaller. It just once font size.

I used your video, I search all topics "ceiling height + label" and I got nothing relevant.

I search these forums before posting. I did not find anything relevant.

I am working on getting my plan and layout templates the way I want them. I was wondering if anyone has ever figured out how to get the room labels to automatically show the ceiling height under the room size? I currently just use text. It would be nice if it jut did that automatically.

Can Iget some help with a project. Its a 12,000 sf building. It takes forever to do anything. Click and wait... Any tips on things I can do to speed up this file?

I have this site plan I am working on. It is tied to the main office building. But I would like to show the shop in the 3D views. How do I bring in a Chief building into this site plan?

I have site plan with two projects on it. The site plan is under the main building project. I want to show the shop on the site plan. How do I do that?
